Concrete Scanning

ClearView owns and operates a Sensors & Software Conquest 100 System for concrete scanning services.  This compact 1 GHz GPR instrument includes an added-on power cable detector.

The results can be displayed as 2D depth sections and plan maps for different lines and depths respectively using off-the-shelf and in-house software.

Exposed rebar can be used to calibrate GPR responses so that standard sizes can be interpreted.  FK Migration allows for better interpretation of the different sizes using depth sections and plan maps of different migrated depths.

Main rebar locations marked on-site

GPR wall scan for rebar

1 GHz scan for voids and leaks under surge pond

Metal bands detected within columns
